Alumina Bubble Refractory Brick 1800C Alumina Hollow Ball Insulating Brick For Ceramic Furnace

Alumina Bubble Brick Introduce

Alumina bubble bricks are made of alumina hollow balls and alumina powder as the main raw materials, combined with other binding agents, and fired at a high temperature of 1750 degrees.It is a kind of ultra-high temperature energy-saving insulation material.Alumina hollow ball bricks have a maximum service temperature of 1800°C and have the advantages of high mechanical strength and low volume density.

Product name Alumina bubble brick
Operating temperature 1750 degrees
Main raw materials Alumina hollow ball material
Properties ultra-high temperature, energy saving, thermal insulation
Features Save materials, save energy

Alumina Bubble Refractory Brick 1800C Alumina Hollow Ball Insulating Brick For Ceramic Furnace

Application

Application of Alumina Bubble Brick

Alumina bubble brick can be used in high-temperature energy-saving (>30%) inverted flame kilns, shuttle kilns, molybdenum wire furnaces, tungsten rod furnaces, induction furnaces, nitriding furnaces, etc. It will achieve obvious results in reducing the weight of the furnace body, transforming the structure, saving materials and saving energy.

Alumina Bubble Refractory Brick 1800C Alumina Hollow Ball Insulating Brick For Ceramic Furnace

Specification

Alumina Bubble Brick Technical Data

Item/Index Alumina Bubble Ball Zirconia Bubble Ball Sialon Binding Al2O3 Bubble Bricks
LKZ-88 LKZ-98 ZKZ-98
Maximum Service Temperature ℃ 1650 1800 2000~ 2200 1600
Al2O3 % ≥ 88 99 70
ZrO2 % ≥ 9.8
SiO2 % ≤ 0.2 0.2
Fe2O3 % ≤ 0.3 0.15 0.2 N≥5
Bulk Density g/cm 1.30~1.45 1.40~1.65 ≤ 3.0 ≤ 1.5
Cold Crushing Strength MPa ≥ 10 9 8 15
Refractoriness Under Load ℃
(0.2MPa,0.6%) ≥
1650 1700 1700 1700
Reheating Linear Change Rate %
1600℃×3hrs
±0.3 ±0.3 ±0.2
Thermal Expansivity ×10
(indoor temperature, ~1300℃)
~8.0 ~8.6 thermal shock resistance,
times (1100℃water cold)≥15
Thermal Conductivity W/(m.K) ≤
(average temperature 800℃)
0.9 1.0 0.5 1.1

Alumina Bubble Refractory Brick 1800C Alumina Hollow Ball Insulating Brick For Ceramic Furnace

Our Services

Rongsheng Refractory has professional sales and after-sale service team who provide customers all-around service about product application, construction installation and operation technology training etc.
